BIG SOUND – SMALL FOOTPRINT This series contains the 4060, 4061, 4062, 4063 and 4071 omni-directional condenser lavalier mics. Each version is tailored towards a specific application based on sensitivity, voltage and placement needs. They are all based on the original 4060, the very first miniature microphone developed by DPA from the best technology previously only used in hearing aids and measurement microphones. All of the mics in the series share important basic features, but each is optimized for particular applications. The series was developed to withstand the toughest of conditions. They contain a 5.4 mm diameter pre-polarized condenser element with a vertical diaphragm. This unique, Double Vent Protection System makes the mics greatly resistant to humidity and sweat. These mics are also designed with a Kevlar-reinforced cable relief, which is built to withstand the constant twists, bends and pulls that are part of the everyday use in harsh environments. ACADEMY-HONORED MINIATURES In 2021, the Academy of Motion Picture Arts and Sciences’ Board of Governors bestowed a Technical Achievement Award to DPA miniature microphones. The award is directed specifically to Jens-Jorn Stokholm and Ole Moesmann for the innovative development of high-performance miniature and subminiature DPA lavalier microphones. 4060 MINIATURE OMNIDIRECTIONAL MICROPHONE, NORMAL SPL This omnidirectional condenser lavalier microphone is small in size, but mighty in flexibility. Due to its miniature size, it exhibits an exceptionally accurate omnidirectional pattern and therefore does not need to be aimed directly at the sound source to achieve quality pickup. The omnidirectional pattern also makes it less sensitive to handling noise as well as pop and wind noise. DPA originally designed this microphone for use with wireless systems in theaters but today it is one of the most loved mics for television and film applications as well. It is especially suited for capturing speech in all of its nuances and can be used to close-mike a wide range of instruments. This microphone handles sound pressure levels up to 134 dB before clipping occurs. This mic is well suited for applications where the sound source is more remote or damped and you need to have a good balance signal versus noise. FEATURES: exceptional audio quality uniform, consistent sound between DPA mics extremely rugged and reliable diminutive size made for flexible and easy concealment large selection of clips, windscreens, grids and other accessories modular adapter system fits most professional wireless systems Directional Pattern Omnidirectional Principle of Operation Pressure Cartridge Type Pre-polarized condenser Frequency Response 20 Hz – 20 kHz Effective Frequency Range Soft boost: 3 dB @ 8-20 kHz; High boost: 10 dB @ 12 kHz Sensitivity 20 mV/Pa; -34 dB re. 1 V/Pa Equivalent Noise Level (A-weighted) Typ. 23 dB(A) Distortion (THD < 1%) 129 dB SPL peak Dynamic Range Typ. 106 dB Max SPL (10% THD) 134 dB SPL peak Rated Output Impedance 30 – 40 Ω Cable Drive Capability Up to 300 m (984 ft) with DAD9001-BC Power Supply Wireless: 5-10 V; Wired: P48 (Phantom Power) Current Consumption Typ. 1.5 mA (mic); 3.5 mA (with adapter) Connector MicroDot Weight 7.5 g (incl. cable/connector) Dimensions 5.4 mm (diameter) x 12.7 mm (length) Cable Length 1.8 m (5.9 ft) Temperature Range -40°C to 45°C
