This mic delivers pristine, natural and undistorted sound with exceptional isolation and off-axis rejection for any live or studio setting. Fitted with MicroLock® and a series of upgraded instrument clips, the 4099 CORE provides even better stability and flexibility on any type of instrument. (The 4099 CORE is fully backwards compatible with all generations of DPA instrument clips and with accessories featuring MicroDot connector, ensuring seamless integration with your existing setup.) This microphone comes in two versions: 4099 CORE Mic, Loud SPL (red marking on gooseneck) – used to close-mic most types of acoustical instruments. – From the harp to the drums and everything in between. With CORE , this mic has a max SPL, peak before clipping of 145 dB. 4099 CORE Mic, Extreme SPL (yellow marking on gooseneck) – used to close-mic extremely loud instruments, such as drums and some brass. Designed for use on drums, percussion instruments and other very loud instruments like, for example, the trumpet, this mic has a max SPL, peak before clipping of 152 dB. You can buy a single 4099 alone or with a specific instrument clip, or you can choose a kit designed specifically for rock or classical applications. These kits come in 4-piece and 10-piece sets combined with the appropriate adapters, clips and cables that make it a breeze to set up your stage. CORE captures an instrument’s true voice – picked up or amplified with DPA’s renowned authenticity. With CORE technology inside, the 4099 captures every nuance with pristine clarity, ensuring that the character of the instrument remains untouched, both on-axis and in the surrounding soundscape . Well-balanced isolation – from surrounding instruments due to the supercardioid polar pattern and linear off-axis response Lightweight, discreet design – ensures that the 4099 blends seamlessly into performances Superior microphone suspension – from enhanced shock mount and microphone body design. Improves isolation from instrument vibrations and stage noise, ensuring a cleaner signal and a more homogenous sound One microphone, ∞ possibilities – upgraded, flexible clip program ensures a secure, reliable fit while treating your instrument with the utmost care. Effortless to attach and adjust, yet firm and reliable in hold, this one microphone model can beautifully reinforce an entire orchestra (The 4099 piano stereo pair have a selected sensitivity tolerance of ±1.0 dB. The 4099 accordion stereo pair have a selected sensitivity tolerance of ±1.0 dB.) ONE MICROPHONE, ∞ POSSIBILITIES From the piano to guitar; strings to woodwinds; brass to percussion, the 4099 Series sounds equally impressive on them all. This one microphone model can beautifully reinforce an entire orchestra. You can move the mic to another instrument; just make sure you have the right type of clip to mount it correctly. DPA’s versatile and practical instrument clip system has been a key selling point since the launch of the original 4099 in 2008. The principle of attaching the clip to the gooseneck has proven highly effective in both classical and rock applications, offering secure and flexible mounting solutions. And now, we have enhanced the clip system – improving not only the acoustic performance of the microphone but also the security, reliability and efficiency of the mounting process. These refinements make it easier to close-mic instruments and adjust capsule positioning for optimal performance. The most significant update is the introduction of a new gooseneck locking mechanism: the Gooseneck Mount (G-MOUNT). By integrating this new locking principle, we have streamlined the mounting process, ensuring greater stability, ease of use and precision of mic placement for musicians and audio professionals alike. DPA 4099 CORE MIC LOUD SPL Directional Pattern Supercardioid Principle of Operation Pressure gradient Cartridge Type Pre-polarized condenser Frequency Response 20 Hz – 20 kHz Effective Frequency Range 80 Hz – 17 kHz (±2 dB @ 20 cm) High Frequency Character 2 dB soft boost at 10-12 kHz Sensitivity (Nominal) 6 mV/Pa; -44 dB re. 1 V/Pa (±3 dB at 1 kHz) Equivalent Noise Level Typ. 23 dB(A) re. 20 μPa Dynamic Range Typ. 118 dB Max SPL (10% THD) 145 dB SPL peak Rated Output Impedance 100 Ω (via DAD9099/DAD9001) Cable Drive Capability Up to 300 m (984 ft) Power Supply P48 (Phantom Power) or 5-10V for wireless Connector MicroLock DPA 4099 CORE MIC LOUD FOR EXTREME SPL Directional pattern Supercardioid Principle of operation Pressure gradient Cartridge type Pre-polarized condenser Frequency response 20 Hz – 20 kHz Effective frequency range 80 Hz – 15 kHz with 2 dB soft boost at 10-12 kHz Sensitivity 2 mV/Pa; -54 dB re. 1 V/Pa Equivalent noise level Typ. 28 dB(A) re. 20 μPa (max. 31 dB(A)) Distortion, THD < 1% 134 dB SPL RMS, 137 dB SPL peak Dynamic range Typ. 109 dB Max. SPL, THD 10% 152 dB SPL peak Rated output impedance From MicroDot: 30 – 40 Ω. From DAD9099-BC or DAD9001-BC: 100 Ω Cable drive capability Up to 300 m (984 ft) with DAD9001-BC/DAD9099-BC XLR Adapter Power supply For wireless systems Min. 5 V – max. 10 V through DPA adapter. With DAD6001-BC or DAD4099-BC: P48 (Phantom Power). Will work from 12 V Current consumption Typ. 1.5 mA (microphone). 3.5 mA with DAD9099-BC or DAD9001-BC XLR Adapter Connector MicroDot FEATURES: CORE technology high SPL handling wide dynamic range supercardioid pick up pattern superior gain before feedback MicroLock® connector IP58 certified advanced, flexible clip program
